Description
CONSTRUCTION: Double walled construction with interior made of stainless steel 304 with 75 mm insulation. Exterior made of Mild Steel painted in Epoxy Powder Coating. Hermetically Sealed Compressor (CFC Free) CFC free refrigerant. Two water tank of stainless Steel with Stem Generation and Low water safety device.
TEMPERATURE & HUMIDITY:
Temperature from 1°C to 60°C ± 2°C. Humidity 55% to 90% ±3 %
CONTROLLER: Microprocessor Controller for temp. & RH Combined with precise control.
- Code: HTICO-0097
| Inner Dimension in mm | Capacity | Volume | No. of Perforated Tray |
|---|---|---|---|
| 455 x 410 x 610mm | 112 Ltrs. | 4.0 Cuft | 2 |
| 505 x 415 x 830mm | 171 Ltrs. | 6.1 Cuft | 2 |
| 605 x 605 x 605mm | 224 Ltrs. | 8.0 Cuft | 2 |
| 570 x 550 x 875mm | 280 Ltrs. | 10.0 Cuft | 3 |
| 650 x 580 x 900mm | 340 Ltrs. | 12.0 Cuft | 3 |
| 700 x 640 x 900mm | 420 Ltrs. | 15.0 Cuft | 4 |
OPTIONAL FOR HUMIDITY CHAMBER/ENVIRONMENTAL CHAMBER
- Communication Port with interface and data cable to download to your PC with PLC & HMI
